Product Overview
The 1.8-meter field crusher is an engineered, high-performance solution designed to transform challenging terrains into highly arable land. Built with a reinforced steel chassis and high-torque hydraulic synchronization systems, this machine effortlessly pulverizes dense topsoil, buried rocks, and stubborn organic debris. Equipped with premium alloy hammers and dual-cylinder hydraulic rear gates, it ensures uniform material crushing and precise depth control in a single pass. For operators tackling tough agricultural or civil engineering projects, it serves as the ultimate Wasteland reclamation machine.
Product Parameters
|
Model |
Working Width (m) |
Overall Dimension |
Weight (kg) |
Matched Power (Wheel Tractor) |
|
Model 1600 |
1.6m |
L2006mm * W1722.5mm * H1426mm |
3560kg |
Tractors above 2204 model with creep gear |
|
Model 1800 |
1.8m |
Not available |
- |
- |
|
Model 2000 |
2m |
Not available |
- |
- |
- Crusher Tools: Imported Blades
Key Applications
Agricultural Land Preparation
Easily achieves thorough Farmland stone breaking, turning rocky fields into smooth, seedbed-ready soil.
Infrastructure & Road Subgrade
Functions as high-efficiency Hard soil crushing equipment to stabilize soil and prep rural roadbeds.
Orchard & Vineyard Clearing
Cleans up deep roots, old stumps, and rocky substrates before replanting.
Civil Forestry & Mining Reclamation
Acts as robust Mountain stone breaking equipment to clear rocky hillsides, steep slopes, and quarry leftovers.
Corporate After-Sales Service
We understand that equipment uptime is critical to your profitability. Our comprehensive global service framework includes:
Warranty: 1-year comprehensive warranty covering core structural and hydraulic components of 1.8-meter field crusher.
Spare Parts Support: Lifelong access to wearing parts (hammers, belts, bearings) shipped via express air freight.
Technical Guidance: 24/7 online video troubleshooting and detailed engineering consultation.
Customization: Tailored hitching systems, hydraulic line lengths, and hammer configurations based on your local soil profile.
Customer Frequently Asked Questions (FAQs)
Q1: What tractor horsepower is required to operate this 1.8-meter crusher effectively?
A: This model requires a tractor with a minimum of 120 to 160 HP, equipped with a 540/1000 RPM PTO and dual-acting hydraulic valves to handle heavy crushing loads.
Q2: How deep can the 1.8-meter field crusher penetrate and crush stones underground?
A: The working depth is hydraulically adjustable, allowing the alloy teeth to penetrate and crush buried rocks up to 15–20 cm below the surface.
Q3: What type of steel is used for the cutting hammers, and how long do they last?
A: We use custom forged tungsten-carbide alloy hammers. Depending on your soil's quartz and granite content, a single set typically lasts between 200 to 400 working hours.
Q4: Can the hydraulic rear gate be adjusted while driving?
A: Yes. The dual red hydraulic cylinders allow the operator to adjust the rear gate on the fly from the tractor cabin, controlling the final soil output size.
Q5: How does the machine handle high-impact shocks from large boulders?
A: The drivetrain features a heavy-duty friction clutch and multiple high-strength V-belts that slip automatically during sudden overloads to protect your tractor's PTO.
Q6: What is the maximum stone diameter this equipment can safely pulverize?
A: It can easily handle and pulverize individual loose stones up to 25–30 cm in diameter, grinding them down into fine gravel or sand mixed with soil.
Q7: Is the hitch system compatible with standard international tractor linkages?
A: Absolutely. It comes standard with a universal Category 2 or Category 3 three-point hitch, ensuring a seamless hookup to standard global tractor brands.
Q8: What is your standard lead time for international container shipping?
A: Our standard production cycle is 15–20 days. Sea freight to major ports in North America, Europe, or Australia typically takes an additional 25–35 days.
